The Double Twist Wrapper with Vibratory Auto Feed is engineered for high-efficiency wrapping in medium to high volume production of a wide array of sweets and confectionery items.
Built in China & UK
×
Built in China
Interested?
Call: +44 (0) 1253 882 961
E-Mail: sales@loynds.co.uk
for more information.
The Double Twist Wrapper with Vibratory Auto Feed is designed for medium to high volume wrapping of various confectionery products like chocolates, boiled sweets, fudges, and caramels. Its integrated vibratory feeding system means the machine requires minimal operator intervention. A single operator can manage multiple machines.
Specifications
- Product Dimensions: Can wrap products with dimensions:
Length : 12-34mm
Width : 12-34mm
Diameter : 6-20mm - Speed: Up to 450 pcs/min
Auto-Feed Operation
The vibratory feed mechanism ensures a steady, automated flow of products into the machine, making it especially suited for high-volume operations.
A sensor positioned over the feed disc regulates the timing of the vibratory candy feed tray, optimising product flow. The machine features a no-product-no-paper system to minimise paper waste.
Safety Features
- Integrated with an electronic safety interlock and a magnetic switch. If the safety guard is lifted during operation, the machine will automatically stop.
- Emergency Stop Button
- Lockable Electric Isolator for safe maintenance
Additional Features
- Double paper feed reel holder for quick reel changeover.
- Print registration device to align printed film onto the wrapped product.
- Air-assisted paper feed system.
- Optical sensor for ‘no product, no film’ detection to save paper.
- Lexan clear guards for enhanced operator safety.
- HMI control system
- Wrapping film length is changed by a keypad and stepper motor.
- Self contained lubrication system.
Explore Less Automated Solutions
If you are interested in a hand-fed model for packaging items that do not feed well automatically – TW03 Hand Feed Double Twist Wrapping Machine.
